DOKIO 400W N-Type Monocrystalline Rigid Solar Panel

High-efficiency module for RV, rooftop & off-grid systems.
Regulärer Preis $254.00
Verkaufspreis $254.00 Regulärer Preis $468.00
Einzelpreis
Sparen Sie 46%
  • 410W rated output (Pmax)
  • 31V Vmp | 37.08V Voc
  • 67.79 × 44.65 × 1.18 in (per module)
  • Pre-installed 3m output cables
  • 25% N-Type monocrystalline cells
  • IP67 waterproof junction box
  • Corrosion-resistant aluminum frame
  • 25-year power output warranty
Vergleichen Stelle eine Frage

Stelle eine Frage

* Benötigte Felder

Größentabelle Aktie
  • Estimated Delivery:Nov 20 - Nov 24

  • Local Warehouse - Free Shipping

DOKIO 400W N-Type Monocrystalline Rigid Solar Panel - DOKIO Solar Panel

DOKIO 400W N-Type Monocrystalline Rigid Solar Panel

Description
Specification
Support

DOKIO 410W monocrystalline solar panel installed on a patio deck, with 25% efficiency, A+ grade cells and PERC technology DOKIO solar panel layer breakdown diagram showing tempered glass, EVA film, monocrystalline cells, aluminum frame and TPT backsheet DOKIO solar panel on a metal rack in snowy conditions, labeled IP67 waterproof and 2400Pa wind resistance DOKIO 410W monocrystalline solar panel specifications sheet showing electrical parameters, 25% efficiency and dimensions Series wiring diagram connecting two DOKIO solar panels to a 48V MPPT charge controller, 48V battery and inverter Parallel wiring diagram connecting two DOKIO solar panels via MC4 connectors to a 30A MPPT charge controller, 24V battery and inverter Installer mounting a DOKIO solar panel on a roof, demonstrating easy installation for all roof types DOKIO solar panel protective packaging with four corner protectors and pearl cotton cushioning DOKIO certifications UL, CE, ISO 9001 and TUV with global service map, 18 years experience and 30+ countries served

Multiple Usage Scenarios

DOKIO solar panel mounted on the roof of a white RV camper van
RVs and Campers
Solar panels on the red tile roof of an off-grid garden cabin
Off-grid cabins
Home solar power system supplying appliances and charging an electric vehicle with battery storage
Home backup
Row of solar panels on a wooden ground mount in a backyard garden
Greenhouses and yards

Electrical Specifications

Maximum Power (Pmax)410W
Power Tolerance±3%
Voltage at Pmax (Vmp)31.00V
Current at Pmax (Imp)13.09A
Open Circuit Voltage (Voc)37.08V
Short Circuit Current (Isc)13.24A
Cell TypeN-Type Monocrystalline
Cell Efficiency25%
Maximum System VoltageDC1000V
Maximum Series Fuse15A

Operating Conditions

Operating Temperature-45°C to +80°C
NOCT45°C ±2°C
Standard Test Conditions (STC)AM 1.5 / 1000W/m² / 25°C

Electrical values are measured under Standard Test Conditions (STC): irradiance 1000W/m², AM 1.5, cell temperature 25°C.

Construction & Protection

Front SurfaceTempered Glass
FrameAluminum
Junction Box RatingIP67
MountingPre-drilled holes for fixed installations

Connection & Integration

Connector TypeMC4 (standard)
Output Cable Length3m factory-installed leads
Cable MarkingTÜV SÜD • IEC 62930 • EN 50618 (PV cable)
Field Wiring RequirementMinimum No.12 AWG copper wire, 90°C insulation minimum
Array WiringPanels ship individually; series/parallel wiring is user-configured
Compatibility12V/24V battery systems & power stations (controller required, not included)

Note: This product includes solar panels only. Series/parallel configuration depends on system design and controller specifications.

Dimensions

Size (per module)67.79 × 44.65 × 1.18 in (1722 × 1134 × 30 mm)
Weight (per module)49.38 lb (22.4 kg)

Package Contents

400W — 1 Panel1 × 400W rigid solar panel
800W — 2 Panels2 × 400W rigid solar panels
1600W — 4 Panels4 × 400W rigid solar panels

Wiring accessories (branch connectors, extension cables) and charge controller are not included unless explicitly stated in the product options.

Warranty, shipping, returns & customer support for DOKIO solar panels and accessories.

Product Warranty

Warranty Coverage
Applies to products purchased directly from the official DOKIO website (dokiopv.com).
Covers defects in materials and workmanship under normal use.
Warranty Time
10-Year Product Warranty
25-Year Power Output Warranty
Warranty Solutions
Repair / Replacement / Prorated refund (as applicable).
Not Covered
Improper installation, misuse, or modifications
Cosmetic damage, normal wear and tear
Damage caused by accidents, shipping mishandling, or external factors
Accessories and consumable parts (unless otherwise stated)
Unauthorized / Second-hand Purchases
Warranty service is not supported for products purchased from unauthorized sellers, second-hand marketplaces, or non-official sales channels.
Original Purchaser
Warranty applies only to the original purchaser and is non-transferable.

Shipping & Delivery

Local Warehouses: United States, Germany, United Kingdom

Processing Time: Ships within 48 hours (business days)

Delivery Time: 2–5 business days depending on location

Tracking: Tracking number provided via email once shipped

Note: Please ensure your shipping address is correct. Report damaged packages within 7 days of delivery.

Returns & Refunds

Return Window: 30 days from delivery date

Condition: Item must be unused and in original packaging

Return Shipping: We provide a prepaid return label for defective, damaged, or incorrect items.

Refund Processing: 7–14 business days after inspection

Contact Us

Need assistance or technical support?
Email us at support@dokiopv.com

Response Time: Within 24 business hours

Frequently Asked Questions (FAQ)

What can a 400W solar panel power?
A 400W solar panel is ideal for RVs, cabins, off-grid systems, and backup power applications. Under good sunlight, a single panel can generate enough energy to recharge batteries, power portable power stations, and support devices such as lights, fans, routers, and small appliances when combined with a suitable battery and inverter system.
How many 400W solar panels do I need for a home backup system?
The number of panels depends on your energy usage, battery capacity, and available sunlight. For example:
• 2 panels = 800W solar array
• 4 panels = 1600W solar array
• 8 panels = 3200W solar array
• 10 panels = 4000W solar array for larger backup systems A larger solar array allows you to recharge batteries faster and better support off-grid or home backup applications.
Can I connect multiple 400W panels together?
Yes. Multiple DOKIO 400W solar panels can be connected together to create a larger solar array. Before connecting multiple panels, make sure your charge controller, inverter, and battery system support the combined voltage and current.
Do I need a battery and inverter for my solar panel system?
A solar panel generates electricity only when sunlight is available. Adding a battery allows you to store solar energy, while an inverter converts stored DC power into usable AC power for household appliances, RV equipment, and backup power applications. A complete solar system with panels, battery storage, and an inverter provides more reliable power day and night.
Is this panel compatible with LiFePO4 batteries?
Yes. When paired with a compatible solar charge controller, the panel can charge LiFePO4 batteries as well as AGM, GEL, and Lead-Acid batteries. Always ensure the charge controller matches your battery voltage, capacity, and solar input specifications.
What size inverter do I need for a 400W solar system?
The inverter size depends on the appliances you want to run and the total size of your solar system. For small applications, a compact inverter may be enough. For whole-home backup systems, multiple solar panels combined with larger battery storage and a higher-capacity inverter are recommended.
Is it easy to mount this panel?
Yes. The panel includes a strong aluminum frame with pre-drilled mounting holes. It can be installed using common solar mounting hardware such as Z-brackets, roof mounts, or adjustable tilt mounts on RV roofs, cabins, or ground structures.
Can it withstand harsh weather conditions?
Yes. The panel is built with tempered glass and a corrosion-resistant aluminum frame, designed for outdoor environments including rain, snow, and wind. The junction box is IP67 waterproof, providing reliable performance in long-term outdoor installations.
Will this work with my power station (EcoFlow / Bluetti / Jackery)?
Yes. The panel can work with many portable power stations that support solar input. Because this is a high-power panel, confirm that your power station supports the panel's voltage and current requirements. An appropriate adapter cable may also be required.

Reviews

Customer Reviews

Based on 25 reviews
92%
(23)
4%
(1)
0%
(0)
0%
(0)
4%
(1)
A
Andy Vanskyock

very fast shipping, great price

D
David

Love this solar panel. Set it up on its mount and with late November full sun light I actually got a full 400 watts!

C
Charles

Working very well at this time you get about 300 watts at best but it charges my batteries really well.

Great result, Charles — 300W in winter is solid, because shorter days and a lower sun angle drag down every panel this time of year. Want a little more? Tilting the panel steeper to face the low winter sun, and keeping the glass clear, can squeeze out noticeably more power. And the cold actually helps — panels run more efficiently as temperatures drop. Enjoy the full batteries!

A
Andy Vanskyock

great value, very fast delivery, can't wait to install

V
Victor

Bad product
